Basic Toilet partition

Basic Toilet Partition with 10 mm compact laminate and profiles in powder coated (white or grey) aluminium. Exposed CNC milled laminate edges. Standard height is 2,030 mm including adjustable column bases measuring 95-150 mm. Exterior door pre-assembled from the factory with self-closing hinges, locks and handles in accordance with our standard. Designed according to customer needs with accompanying drawings.

Välj mellan vit eller antracit kulör på beslagen/profiler:

Vit RAL9016

Antracit RAL7043

Klädkrok, art.nr AP854001

För andra kulörer/mönster så hänvisar vi er till Abet Laminati Abet Laminati – Home eller kontakta oss för rådgivning.

Wall and partition panel format:

Front walls 1888×1300 mm. Partition walls 1904×1300 mm.

Door format 1860×620 or 1860x920mm

Frame

Constructed of high-pressure laminate (compact laminate) 10 mm thick. ISO4586/EN438.

Profiles/fittings

Powder coated profiles/brass fittings of which the majority are pre-drilled and cut to the correct lengths. The laminate is fixed to the profiles/fittings using a hidden attachment system.

Floor pillars

Column bases are adjustable between 95-150 mm.

Hinges

Always supplied with self-closing hinges. The doors come from the factory with the front wall pre-assembled. The hinges are fitted at the factory for maximum durability. The doors have rounded polished edges.

Delivery

According to drawings. Each order comes with an accompanying drawing and installation instructions as per the design documentation.

Machining

Basic can be sawed and drilled using customary woodworking tools with carbide blades. The edges can be ground and polished, but they do not need to be painted or protected from moisture in any other way.

Water resistance

The homogenous laminate tolerates moisture and water. It is not attacked by mould or rot. The walls can be washed using a high-pressure washer, which is a requirement imposed by many industries for cost-effective cleaning.

Impact resistance

High pressure laminate is one of the market’s most tolerant building materials. The laminate has a hard and resilient surface that is incredibly difficult to make impression marks in.

Hidden
